OUR BUSINESS

Screen Shot 2565-04-05 at 16.00.37.png
fbcf20_994a8034bde548ff902f2acfa40949aa_mv2 (1).png

MANUFACTURING
EQUIPMENT

Food

TECHNOLOGY AND FOOD SAFETY

JINPAO provide manufacturing of equipment for food industry, included:



  • food scanners

  • vending machines

  • X-Ray Metal Checker

  • Automatic Combination Weightier

  • Milk Analyzer

Image by Tobias Reich

CHARGER & SWAPPING
EQUIPMENT

Energy

FEATURE AND SPECIFICATION

RFID / Scan payment

Full charging time : 1~5 hours (depend on type of battery) Charging power :
72V 40A max 2880W

Charge 2 battery / station Charge status indicator and alert sound.

Screen Shot 2565-04-05 at 16.22.47.png
Screen Shot 2565-04-05 at 16.23.06.png

SHEETMETAL FABRICATION

Punching & Laser Cutting

Our punching machines can accommodate up to 3600mm length material. They can reach up to 500 hits per minute. One punching machine is equipped with cycle loader to fully automate production. This machine combination can run 24hrs without operator. Laser can cut up to 25 mm mild steel. This is equipped with shuttle table to allow unloading and material setting while the machine is running.

JINPAO using the latest electrically-driven punching machine and the flying optic laser from AMADA.


Bending

Equipped with a newly-developed AMNC 3i (intelligent, interactive, integrated) control, the HG series provides high-speed and high accuracy. Enhanced database network features provide better communication between the CAM program and the AMNC 3i — resulting in less manual interaction and faster processing.

JINPAO’s new HG press brake machines from AMADA can handle a full range of material thicknesses in bend lengths up to 4300mm.

Forming

JINPAO’s Triform Fluid Cell press can be thought of as high-performance alternatives to traditional solid-block rubber pad forming. Pad forming typically applies pressure of 1,000 – 1,500 PSI on the part, our sheet hydroforming presses offer 5,000 PSI on the part and place uniform pressure on every square mm of the part’s surface. The result is reduced material wrinkling, increased definition, and often it eliminates the need for manual hand-finishing.

Fluid Cell sheet hydroforming creates parts with a single unmated tool, using the downward force of the pressurized bladder.


MACHINING & TURNING

5-axis machining provides infinite possibilities as to the part sizes and shapes JINPAO can effectively process. On a 5-axis machining center, the cutting tool moves across the X, Y and Z linear axes as well as rotates on the A and B axes to approach the work piece from any direction. In other words, we can process five sides of a part in a single setup.

3-Axis Vertical Mill

5-Axis Vertical Mill

ADDED-VALUE ASSEMBLY

Our expertise in a variety of technologies consolidates your supply chain and results in streamlined shipping, accounting and auditing functions for our customers. We provide a value-added assembly solution (included testing after integration) customized for your company’s needs:

At JINPAO, we take a holistic approach to building your device and equipment. From the design and manufacture of each individual part to the full assembly, you get a plug-and-play tested unit that you know will function as intended.

DESIGN & MANUFACTURE

value-added assembly solution for plug-and-play tested units (included testing after integration)

  • Telecommunication Cabinets

  • Entertainment Products

  • Infrastructure Devices

  • IoT Devices

  • Kiosks terminals

Screen Shot 2565-04-05 at 13.30.10.png
Screen Shot 2565-04-05 at 13.30.14.png

ENGINEERING SERVICES

Design / Prototyping / Testing

In-house solution
(included testing after integration)

  • DFM Service

  • Co-design

  • CAD Systems

    (Autocad, CATIA, SolidWorks)

  • Cyber Physical Simulations

    (PAM-Stamp)

  • Paperless Hyper Document – PHD

  • Project Management

    with FMEA risk analysis

Screen Shot 2565-03-31 at 16.16_edited.jpg

Jet Machining Center


MATERIAL TYPE

Aluminum, Stainless Steel, Inconel, Copper Alloys, Nickel Alloy, Titanium

Plate, Sheet, Bars, Extrusion, Die Casting

STANDARD MODEL SPECIFICATIONS

Material Support Slats

34 4" × 14Ga Galvanized Steel
(102 mm × 2 mm)

Maximum Supported
Material Load

300 lbs/sq ft
(1,465 kg/sq meter)

Electrical Requirements

3-Phase, 380-480 VAC +10%,
50-60 Hz

500 in/min (12.700 mm/min)

Speed

‡0.002" +0.051 mm)

Repeatability

WORK ENVELOPE

X-Y Cutting Travel*

10'0" × 5'2"

(3,061 mm x1,575 mm)

Z-Axis Travel*

12" (305 mm)

Table Size*

12'2" x 5'8"
(3,708 mm x1,740 mm)

SPECIAL PROCESS

MATERIAL TYPE

Aluminum, Stainless Steel, Inconel, Copper Alloys, Nickel Alloy, Titanium

Plate, Sheet, Bars, Extrusion, Die Casting

CHEMICAL PROCESS

- Chemical Conversion Coating

- Sulfuric Acid Anodize

- Boric Sulfuric Acid Anodize(BSAA)

- Tartaric Sulfuric Acid Anodize(TSAA)

PAINT & COATING

Liquid Paint

Powder Paint

NON-DESTRUCTIVE TESTING

- Type 1, Method A, Sensitivity Level 3

WELDING

- Gas Tungsten Arc Welding

- Laser Welding

- Resistance Spot Welding

HEAT TREATMENT FOR ALUMINUM

- Solution Treatment - T4

- Artificial Aging - T5

- Quenching (less than 10 seconds)

- Shot blasting


Chemical Process


Powder Paint


Non-Destructive Testing


Welding

mechanical parts / assembly / health / food / energy

AEROSPACE

Mechanical Parts

MATERIAL TYPE

Aluminum, Stainless Steel, Inconel, Copper Alloys, Nickel Alloy, Titanium

Plate, Sheet, Bars, Extrusion, Die Casting

Screen Shot 2565-04-05 at 13.09.png
Screen Shot 2565-04-05 at 13.30.10.png
Screen Shot 2565-04-05 at 13.30.14.png

INTEGRATION

Assembly

DESIGN & MANUFACTURE

value-added assembly solution for plug-and-play tested units (included testing after integration)

  • Telecommunication Cabinets

  • Entertainment Products

  • Infrastructure Devices

  • IoT Devices

  • Kiosks terminals

Screen Shot 2565-04-05 at 13.49.09.png
Screen Shot 2565-04-05 at 13.49.09.png
Screen Shot 2565-04-05 at 13.49.16.png
Screen Shot 2565-04-05 at 13.49.16.png

MEDICAL EQUIPMENT

Health

MANUFACTURING

Precision metal parts for a medical equipment, included :

  • Implants & instrumentations

  • X-Ray systems

  • Surgical Operation Tables

  • Smart Vital Signs Station
